Baku Olympic Stadium Project


Located on the shore of Lake Boyuk Shor in Baku, the Baku Olympic Stadium is a multi-purpose facility sited on a 496,000 m² plot with a seating capacity of 68,000. The project required robust surface-water management for large plazas, circulation areas and service roads, along with safe access solutions—while preserving the architectural quality of this landmark through a coherent design language.

Mert Döküm supported the project with EN 124 / EN 1433 compliant systems that combine high hydraulic capacity with heavy-duty load performance and aesthetic integration. Key products: M121 Manhole Cover, M160 Stormwater Grating, M138 Point Drain Grating and Mk800P Access Cover.


M121 Manhole Cover
EN 124 • C250–D400

M121 Manhole Cover

M121 provides secure access to underground networks in pedestrian zones, entrance plazas and technical corridors. Durable with a compact, architect-friendly form.

  • Ductile iron EN-GJS-500-7, corrosion resistant
  • Anti-slip surface, secure locking
  • Flush installation with the paving
  • Easy to apply and install.
M121 Technical Drawing
M160 Stormwater Grating
EN 124 • D400–E600

M160 Stormwater Grating

M160 is used on service roads and emergency routes exposed to heavy vehicular traffic. A strong frame–grating interface with locking options prevents displacement and improves safety.

  • Body with anti-theft locking
  • Double-sealed, watertight variants
  • Optional embossed branding
M160 Technical Drawing
M138 Point Drain Grating
Code: M138 • Load Class: D400

M138 Point Drain Grating

M138 is used for point drainage in stair voids, perimeter lines and car parks in urban infrastructure applications. High inlet efficiency with an anti-slip surface ensures safety.

  • Material: GGG 50 (ductile iron)
  • Coating & colour: Bituminous paint
  • Gasket: EPDM rubber
  • Compatible with DN100–DN200 outlets (application-dependent)
M138 Technical Drawing
Mk800P Access Cover
Metal Product

Mk800P Access Cover

Mk800P is a durable access cover for outdoor and technical areas around the stands. It combines hydraulic capacity, pedestrian safety and aesthetic design.

  • Hot-dip galvanised; high corrosion resistance
  • Anti-slip load bars; pedestrian/trolley friendly
  • Alternative pattern options
  • Compatible with EN 1433 channel systems
Mk800P Technical Drawing

Standards, Performance & Project Benefits


Compliance & Materials
• EN 124 (manhole & access covers), EN 1433 (linear drainage)
• Ductile iron EN-GJS-500-7, stainless & galvanised steel
• High hydraulic capacity
• Low maintenance, long service life

Key Benefits
✅ Strength under pedestrian and vehicular traffic
✅ Secure locking & anti-slip surface
✅ Fast installation and easy access
✅ Architecturally compatible, aesthetic details
